Intel Core Ultra 5 225 processor 20 MB Smart Cache Box

Data sheet

Processor model

225

Processor family

Intel Core Ultra 5

Processor cores

10

Processor boost frequency

4.9 GHz

Maximum internal memory

192 GB

Performance cores

6

Processor manufacturer

Intel

Efficient cores

4

Processor cache type

Smart Cache

Processor generation

Intel Core Ultra (Series 2)

Maximum turbo power

121 W

Processor base power

65 W

Processor cache

20 MB

Discrete graphics card

No

On-board graphics card

Yes

On-board graphics card model

Intel Graphics

Discrete graphics card model

Not available

Processor threads

10

Execute Disable Bit

Yes

Embedded options available

Yes

Memory channels

Dual-channel

Intel® Thunderbolt 4

Yes

Enhanced Intel SpeedStep Technology

Yes

Intel 64

Yes

Efficient-core boost frequency

4.4 GHz

Performance-core base frequency

3.3 GHz

Efficient-core base frequency

2.7 GHz

Performance-core boost frequency

4.9 GHz

Processor operating modes

64-bit

Neural processor unit (NPU)

Intel AI Boost

Windows Studio effects support

Yes

AI software frameworks supported by NPU

DirectML
ONNX RT
OpenVINO
WebNN
Windows ML

Sparsity support

Yes

NPU performance up to

13 TOPs

Total processor performance up to

23 TOPs

Processor socket

FCLGA1851

PCI Express slots version

4.0
5.0

On-board graphics card OpenGL version

4.5

On-board graphics card DirectX version

12.0

Intel® Secure Key

Yes

Intel® OS Guard

Yes

Supported instruction sets

AVX 2.0
SSE4.1
SSE4.2

Processor ARK ID

241070

Thermal Monitoring Technologies

Yes

Intel® AES New Instructions (Intel® AES-NI)

Yes

Intel® Quick Sync Video Technology

Yes

Intel VT-x with Extended Page Tables (EPT)

Yes

Intel Virtualization Technology (VT-x)

Yes

Intel Trusted Execution Technology

Yes

Intel Virtualization Technology for Directed I/O (VT-d)

Yes

Launch date

Q1'25

Market segment

Desktop

Use conditions

PC/Client/Tablet

Processor codename

Arrow Lake

Maximum number of PCI Express lanes

24

Idle States

Yes

Maximum internal memory supported by processor

192 GB

Memory types supported by processor

DDR5-SDRAM

OpenCL version

3.0

Xe-cores

2

GPU performance up to

4 TOPs

Status

Launched

Box

Yes

Maximum number of DMI lanes

8

On-board graphics card refresh rate at maximum resolution (DisplayPort)

60 Hz

On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)

60 Hz

On-board graphics card refresh rate at maximum resolution (HDMI)

60 Hz

On-board graphics card base frequency

300 MHz

On-board graphics card ID

0x7D67

On-board graphics card dynamic frequency (max)

1800 MHz

On-board graphics card outputs supported

DisplayPort 2.1
Embedded DisplayPort (eDP) 1.4b
HDMI 2.1

Number of displays supported (on-board graphics)

4

Direct Media Interface (DMI) Revision

4.0

Scalability

1S

Intel® Turbo Boost Technology

2.0

Mode-based Execute Control (MBE)

Yes

Intel® Deep Learning Boost (Intel® DL Boost) on CPU

Yes

Intel® Volume Management Device (VMD)

Yes

Intel® Thread Director

Yes

Intel® Speed Shift Technology

Yes

Intel® Standard Manageability (ISM)

Yes

Intel® Control-flow Enforcement Technology (CET)

Yes

Intel® Boot Guard

Yes

Graphics output

DP2.1 UHBR20, HDM2.1 FRL 12GHz, eDP1.4b

L2 cache

22528 KB

Memory clock speeds supported by processor

6400 MHz

AI software frameworks supported by CPU

DirectML
ONNX RT
OpenVINO
WebNN
Windows ML

Intel® Deep Learning Boost (Intel® DL Boost) on GPU

Yes
